Model |
86A01 |
Name |
Slippery |
Wall thickness |
0.9mm |
Meter weight |
0.604kg/m |
|
|
Model |
86A02 |
Name |
sliding |
Wall thickness |
1.0mm |
Meter weight |
0.924kg/m |
|
|
Model |
86A02A |
Name |
sliding |
Wall thickness |
1.0mm |
Meter weight |
0.944kg/m |
|
|
Model |
86A03 |
Name |
Edge seal |
Wall thickness |
1.0mm |
Meter weight |
0.488kg/m |
|
|
Model |
86A04 |
Name |
Up and down |
Wall thickness |
0.8mm |
Meter weight |
0.370kg/m |
|
|
Model |
86A06 |
Name |
Light enterprise |
Wall thickness |
0.8mm |
Meter weight |
0.396kg/m |
|
|
Model |
86A07 |
Name |
Hook enterprise |
Wall thickness |
0.8mm |
Meter weight |
0.443kg/m |
|
|
Model |
86A11 |
Name |
Middle waist |
Wall thickness |
0.9mm |
Meter weight |
0.900kg/m |
|
|
Model |
86A19A |
Name |
Pressure line |
Wall thickness |
0.6mm |
Meter weight |
0.083kg/m |
|
|
Model |
86A20 |
Name |
Middle column |
Wall thickness |
0.8mm |
Meter weight |
0.584kg/m |
|
|
Model |
86A30 |
Name |
Press plate |
Wall thickness |
0.8mm |
Meter weight |
0.239kg/m |
|
|
Model |
86A30A |
Name |
Press plate |
Wall thickness |
1.0mm |
Meter weight |
0.341kg/m |
|
|
Model |
86A40 |
Name |
Screen Window |
Wall thickness |
0.6mm |
Meter weight |
0.215kg/m |
|
|
Model |
86A00 |
Name |
Fixed on |
Wall thickness |
0.9mm |
Meter weight |
0.516kg/m |
|
|
